Basic Info.

Model NO.	Switch
Condition	New
Installation Mode	DIN Trail/Wall-Mountable
Protection Grade	IP40 Aluminum Case
Operating Humidity	5%~90% Non-Condensing
Storage	-40ºC~85ºC
Operating Temperature	-40ºC~75ºC
Redundant Power Input	DC 9-56V
Power Access Mode	Phoenix Terminal, DC Seat
Power Consumption	Full-Load<15W
Power Reverse	Support
Transport Package	Cartons
Specification	700g
Trademark	Takfly/OEM
Origin	China
HS Code	8517629900
Production Capacity	5000PCS/Week

Product Description

Fiber Optica switch Product Name:
DF-4FG-4PGIW 10-100-1000M 4 ports Industrial Managed POE Switch
Fiber Optica switch Features:
STP, EAPS/ERPS
Multicast: IGMP Snooping V1/V2/V3, GMRP
VLAN: IEEE 802.1Q 4K VLAN, QINQ
Link Aggregation: manual / static / LACP
QOS: COS, DSCP,8 queues, WRR/SP/WFQ scheduling, QOS Policy
Management Function: CLI/WEB/SNMP, and Primestone NIS management system
Diagnostic Maintenance: Port mirroring, Syslog, Ping
Alarm management: 1 way relay alarm output, RMON, SNMP Trap
Security DHCP Snooping, Option 82, 802.1X, User hierarchical management, ACL,DDOS, port based MAC
filtering / binding
Data control: Port-based ingress/egress speed limit, Full duplex IEEE 802.3x, half duplex back-pressure
flow control. Broadcast storm suppression, Unknown-Multicast suppression and Unknown-Unicast
suppression.
Fiber Optica switch Application:

Fiber Optica switch Parameters:

Technical Parameter:
RJ45 port and speed	4x10/100/1000Base-TX
Fiber port and speed	2x100/1000Base-FX SFP
Standard:	IEEE802.3,IEEE802.3u,IEEE802.3ab ,IEEE802.3z ,IEEE802.1q,IEEE802.1p,IEEE802.1d
Wavelength:	850nm/1310nm/1550nm
Transmission mode	Store and Forward(full/half duplex mode)
Exchange property	Delay time: < 7μs Backplane bandwidth: 1Gbps Packet forwarding rate: 148810 (64Byte)
Power	Connect-always
RJ45	Link/Act: connect-always; data exchange-twinkle Speed light: 100Mbps-always; 10Mbps-twinkle
Fiber	Link/Act: connect-always; data exchange-twinkle
Power access mode	Phoenix terminal, DC seat
Redundant power input	DC 9-56V
Overload protection	Yes
Power reverse	Support
Power consumption	Full-load<15W
Operating Temperature	-40ºC~75ºC
Storage	-40ºC~85ºC

FQA :1. Q: Are you a manufacturer?
A: yes, we are a manufacturer in Shenzhen, China2. Q: What's your MOQ?
A: MOQ can be 1 pcs, but we do not suggest to order 1 pcs because the cost will be higher, so that the price will be higher than your budget.3. Q: What's the price?
A: The price is according to your quantity. After you let us know your quantity, we will offer our best price for you. Big Quantities will get a very competitive price.4. Q: Can you quote FOB price?
A: yes we can, most are delivery by air, DHL, TNT, UPC, FEDEX, etc. For big quantity we will deliver it by sea. The best way is to let us know your detailed specifications and quantity, we will offer the freight with products price for your reference.We have a very competitive price shipping forward.EXW price or CFR price will be better . You can contact us for more solution if you need.5. Q: How is your quality?
A: Our production is according to IEC, Europe standard production, almost closed to the dust-free workshop. Imported production equipment and quality control equipment . Especially MTP Daisi equipment.All the products are 100% test before delivery.6. Q: What's your lead time?
A: For fiber optic patch cord, the lead time can be 2 -3 working days for 5000 pcs. regular products we have in stock. We can deal with urgent orders for you. For more information, you can feel free to contact us.7. Q: What's your warranty?
A: for patch cord, we have 2 years warranty since delivery, but only responsible for non-artificial damage. For artificial damage, we can repair it for you for free, but freight will be paid by your side.8. Q: What's your packing?
A: We are using an international export package. attached some packing of different products for your reference. We also can print your logo on the packing.9. Q: Can you do OEM/ODM?
A: yes, we can. We are a manufacturer, all products accept OEM /OD M. we can sign the Confidentiality Agreement.10. Q: Can I have a sample?
A: It depends on which products, Free sample provide under 10 usd. Freight paid by buyer before delivery.
11. Q: How can I order?
A:
1. send mail to us or send inquiries with product name, specifications, and quantity. Provide your receive address if you need us to figure out freight for you.
2. We will offer our quotation with lead time.
3. After the quotation confirmed, we will send a PI with our bank account.
4. Production will be arranged after the payment received.
5.Confirm the consignee with you before we deliver it.
6.The tracking number will be provided after the delivery.
12. Q: What your payment term?
A: T/T, Western Union, Paypal, MoneyGram at once. For big amounts, can 50% deposit in advance, 50% balance paid before delivery.
Workshop:

Certificates:
ISO9001, ISO1400, CE, RoHS, CPR, ANATEL certified

Exhibitions:
OFC, CommunicAsia, ECOC, Netcom, SVIAZ ICT, AFRICACOM, CAIRO ICT, etc.
