Brief introduction: WD-P1004M-PoE Guide rail type non-network tube type industrial Ethernet switch is a 4-port intellige
Basic Info.
| Model NO. | WD-P1004M-PoE |
| Power over EthernetPower over Ethernet | DC55V, 30W, Plain Ethernet cable |
| Weight | 1.7kg |
| Power Interface | 1 *pluggable 5-core terminal |
| Power source | AC 85V-265V 60/50Hz |
| Transport Package | Inner Box and Paper Carto |
| Specification | 59*160*235(LxWxH) |
| Trademark | Wondertek |
| Origin | China |
| HS Code | 8517699000 |
| Production Capacity | 50000/Year |
Product Description
Brief introduction:
WD-P1004M-PoE Guide rail type non-network tube type industrial Ethernet switch is a 4-port intelligent non-network tube Ethernet switch, and the port supports PoE (Ethernet Power supply). The power supply per port is 30w. The switch can supply power to the IEEE 802.3af/at device (PD) without additional wiring, and supports IEEE 802.13u 802.3x, 100 1000M, full duplex, MDI/MDI-X automatic induction, providing an economical, effective and efficient solution for your industrial Ethernet network.
Specification:
| Item | WD-P1004M-PoE |
| Interface | 4*LAN10/100/1000Base-TX applied for RJ45 interface |
| LED display lights | PWR(power light), PLC(PLC signal light),ETH(Ethernet light) PoE(PoE signal light) |
| protocol | IEEE 802.3 IEEE 802.3u 10/100/1000Ethernet StandardIEEE802.3at Standard |
| Support operating system | Windows 98/ME/NT/2003/7 Windows XP Home/Pro Mac OSX Linux |
| Power over Ethernet | DC55V 30W Plain Ethernet cable |
| Power source | AC 85V-265V 60/50Hz |
| Operating environment | working temperature:-20ºC-85ºCworking humidity 10%-90% non-condensed state |
| Size | 59*160*235(L×W×H) |
| Weight | 1.7kg |
| Certification | CE ROHS |
| Shell | Metal |
| Protection grade | IP40 |
| Power Interface | 1 *pluggable 5-core terminal |
Features:
(1) comply with IEEE 802.3at/af PoE standard;
(2) power supply for each PoE port can reach 30 W;
(3) AC85-260V power input;
(4) -40 ~85 °C operating temperature;
System architecture:
